Hobbywing EzRun 3652/3665 SD G3 Brushless Motor 1/10th On-road Off-road Short Course Truck (Light-duty)

$49.90 USD
<
The evolution of a sensored motor,increases performance.
The EzRun 3652/3665 SD G3 features an improved waterproof sensored cable interface and an upgraded sensored mode to achieve motor temperature protection and perfectly matches the EzRun MAX10 G2 ESC.

Powerful hardware configuration, efficiency is greatly improved The high-precision Hall sensor components ensures that the rotor position output is always accurate and consistent, achieving excellent linearity and a great throttle control.
The EzRun 3652/3665 G3 motor adopts a high precision bearing that is waterproof in the front end of the motor.
The rear end of the motor uses precision iron cover with a smaller structure to improve the capacity, and at the same time, provides a higher bearing speed while keeping resistance low.
The operation is smoother and more reliable.
The stable power and high output of the motor, makes throttle control for maneuvers (power wheelies, straight line power, and clearing jumps) much easier.

The motor adopts a modular detachable structure design
The motor adopts a modular detachable structure design for easy disassembly and daily maintenance.
This helps to prolong the lifespan of the motor and maintaining the efficiency of the motor simple.

Applicable to All Weather & Track Conditions
The IP-67 waterproof system guarantees excellent waterproofing and dustproofing protection.
The whole power system is able to drive on a variety of surfaces including mud, sand, ice, snow and water without damaging the power unit.

Download the manual Here

Specification:
EZRUN 3652SD-3300KV G3
Part Number: 30402603
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 4
KV Rating: 3300KV
LiPo Cells: 2-3S
No-load Current(A): ≤3.9A
O.D.(mm): 37
Length (mm): 53
Shaft Diameter (mm): 3.175
Weight (g): 228
Front Bearing: D13*D5*T4
Rear Bearing: D11*D5*T5
Applications: 1/10thOn-road/Off-road Short Course Truck(Light-duty)

EZRUN 3652SD-4100KV G3
Part Number: 30402605
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 4
KV Rating: 4100KV
LiPo Cells: 2-3S
No-load Current(A): ≤5.0A
O.D.(mm): 37
Length (mm): 53
Shaft Diameter (mm): 3.175
Weight (g): 228
Front Bearing: D13*D5*T4
Rear Bearing: D11*D5*T5
Applications: 1/10thOn-road/Off-road Short Course Truck(Light-duty)

EZRUN 3652SD-5400KV G3
Part Number: 30402606
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 4
KV Rating: 5400KV
LiPo Cells: 2S
No-load Current(A): ≤6.8A
O.D.(mm): 37
Length (mm): 53
Shaft Diameter (mm): 3.175
Weight (g): 227
Front Bearing: D13*D5*T4
Rear Bearing: D11*D5*T5
Applications: 1/10thOn-road/Off-road Short Course Truck(Light-duty)


EZRUN 3665SD-2400KV G3
Part Number: 30402604
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 4
KV Rating: 2400KV
LiPo Cells: 2-4S
No-load Current(A): ≤5.2A
O.D.(mm): 37
Length (mm): 65.8
Shaft Diameter (mm): 5.0
Weight (g): 304
Front Bearing: D16*D5*T5
Rear Bearing: D11*D5*T5
Applications: 1/10thOn-road/Off-road Short Course Truck(Light-duty)

EZRUN 3665SD-3200KV G3
Part Number: 30402607
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 4
KV Rating: 3200KV
LiPo Cells: 2-3S
No-load Current(A): ≤7.1A
O.D.(mm): 37
Length (mm): 65.8
Shaft Diameter (mm): 5.0
Weight (g): 304
Front Bearing: D16*D5*T5
Rear Bearing: D11*D5*T5
Applications: 1/10th Short Course Truck Truggy/Monster

EZRUN 3665SD-4000KV G3
Part Number: 30402608
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 4
KV Rating: 4000KV
LiPo Cells: 2-3S
No-load Current(A): ≤8.2A
O.D.(mm): 37
Length (mm): 65.8
Shaft Diameter (mm): 5.0
Weight (g): 297
Front Bearing: D16*D5*T5
Rear Bearing: D11*D5*T5
Applications: 1/10th Short Course Truck Truggy/Monster
