F4 Brushless Flight Controller and ESC V2.0 (BLHeli_32) F405 4S Brushless Flight Controller 16A

$66.99 USD
F4 Brushless Flight Controller and ESC V2.0 (BLHeli_32) F405 4S Brushless Flight Controller 16A

SPECIFICATIONS OF FC
CPU: STM32F405 (Overclock to 240MHz)
Six-Axis: MPU6000
Size: 26mm x 26mm, whoop mounting pattern
Firmware version: BETAFPVF405 (BEFH)
OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)
RX3 and TX3 are with auto inverter, supporting all RX including TBS Micro RX
TX01 and RX01 ports are available for Frsky F-Port, DSM2/DSMX
Buzzer solder pads
Support programable LED like WS2812 etc
Weight: 4.2g

DIAGRAM FOR F405 4S FC



SPECIFICATIONS OF ESC
Support BLHELI_32
Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, Dshot1200
Input voltage: 3-4S lipo
Cotinue current: 16A
Peak current: 19A
Firmware target: BETAFPV-16A-32bit
MCU: STM32F051K66
Motor Connectors: 1.25mm header pins connector
Weight: 4.4g (7.7g with XT30 cable)



PARTS UPDATED
F405 4S FC board has added extra 4 pluggable ports for ESC, VTX, RX and LED board, convenient installation and decreasing the dislocated PIN mounting.




Using single N-channel MosFETs on ESC board, which has a lower inner resistance. It is dual MosFETs on the original BLHeli_32 ESC board. Current sensor included.


BLHeli_32 ESC is soldering with 25V/220uf electrolytic capacitor, for reducing the defective rate caused by the instantaneous high voltage.



RECOMMENDED PARTS LIST
Frame:  Beta85X 95X frame
Motors: 1105 5000KV motors with 1.5mm header pins connector
Battery: 450mAh 4S battery
Props: 2" 4-Blades Props



PACKAGE    (Please note Send by your Choice)
1 x F405 4S Brushless Flight Controller
1 x 16A BLHeli_32 ESC
1 x 4P Cable for RX
1 x 3P Cable for LED board
4 x M1.4x4mm screws
4 x 1.2mm Anti-vibration ruber dampers
